Antares Doble W - Bass Trap - Wall

Performance

1/3 Oct. from 32Hz to 160Hz | 1 Oct. from 250Hz to 8 KHz

Features

Type:
Pistonic Diaphragmatic Absorber
Absorption Range: 80 Hz to 120 Hz
Peak Absorption Frequency: 90 Hz

Purpose
 - Room mode control
 - Bass ratio control
 - Low frequency RT reduction
 - Improving low frequency response
 - Reducing low frequency time decay
With a peak absorption from 80 Hz to 120 Hz, the Wall Bass Trap offers an enriched acoustic experience, directly attenuating standing waves. The various front designs available for the Wall Bass Trap allow you to create artistic patterns when mounted on the walls of your home cinema or living room, completely indistinguishable from the Artnovion absorber range.
The Wall Bass Trap - 595 x 1190 - equivalent to 2 standard panels, is equipped with a weighted pistonic membrane enclosing a volume with a high performance acoustic core. This design allows for a precisely tuned, high performance absorption. Bringing you the maximum performance in as least space as possible.

Invisible Bass Trapping

Recommended for
- Vertical Wall
- Small Room Acoustics
- Acoustic pressure zones
Pistonic Diaphragmatic Absorber Pressure Core
High Density velocity Core
Effective in both velocity and pressure modal zones
Maximum performance, minimum thickness.


This product is available in the following Fire Rate:
FG | Furniture Grade

_______

PRODUCT COMPOSITION:

Antares Doble W - Bass Trap - Walll | Natural Wood
- Natural wood
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam

Antares Doble W - Bass Trap - Wall | Lacquered Wood
- Lacquered wood
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam

_______

Dimensions:
Antares Doble W - Bass Trap - Wall | 595x1190x58mm
- Equipped with eight M6 Screw Thread receiver


These panels can only be installed on vertical walls. Not for ceiling use.



Fixing Systems: Fixart Tube
FixArt Tube is a innovative system for acoustic panels. Easy to install, easy to align, Simply follow our template and attach the clip fixture to your surface, and then to the corners of your panel, clip them both into the tube, and you're done! With easy adjustment once mounted, and an easy clip-in, clip-out.

Antares Doble W - Bass Trap - Wall

Overview

Features
Type:
Pistonic Diaphragmatic Absorber
Absorption Range: 80 Hz to 120 Hz
Peak Absorption Frequency: 90 Hz
Purpose
 - Room mode control
 - Bass ratio control
 - Low frequency RT reduction
 - Improving low frequency response
 - Reducing low frequency time decay
Recommended for
- Vertical Wall
- Small Room Acoustics
- Acoustic pressure zones
Dimensions:
595x1190x58mm

Available Finishes:

Front
Fabric

Configure your product and contact us for more information
