Norma - Panelling

Distinguished mid range absorption
Features

Type:
Absorber

Absorption Range:
315 Hz to 3150 Hz

Acoustic Class:
C | (aw) = 0,7

Purpose

- RT reduction

- Improving speech intelligibility

- Extended mid-low frequency Absorption

- High frequency absorption

- Noise Reduction



It is often said that less is more and simplicity is the ultimate sophistication.
Norma might just be the materialization of these concepts. Designed with a uniform perforation pattern, this panel is completely focused on mid-frequency absorption, which makes it a very useful tool to shape the acoustics of offices, auditoriums, restaurants or any room where speech is the main sound source. The Norma design comes in 4 different perforation sizes, each tuned to a certain frequency range, and it is available in a selection of wood and lacquered finishes. It is installed with a simplified direct screw system designed for quick, easy installation and maintenance.
Performance

Norma 8 / Norma 10 / Norma 12 / Norma 16

It is often said that less is more and simplicity is the ultimate sophistication.

Recommended for

- Offices

- Conference Rooms

- Meeting Rooms

- Schools

- Auditoriums





Carbon positive Natural Wood - Carefully selected wood from controlled, sustainable sources.

Recycled PET absorption - Class 1 product according to the OEKO-TEX@ Standard 100.
_______

This product is available in the following Fire Rates:
FG | Furniture Grade
FR | Fire Rated
_______

PRODUCT COMPOSITION:

Norma | Natural Wood Veneer (FG)
- Natural Wood Veneer
- Marine Grade Plywood Structural Frame
- Sound PET acoustic core - Euro Class B

Norma | Primer Finished HMDF (FG)
- Primer Finished HMDF *
- Marine Grade Plywood Structural Frame
- Sound PET acoustic core - Euro Class B

Norma | Natural Wood Veener (FR)
- Natural Wood Veneer
- Fire Retardant HMDF Structural Frame
- Sound PET Acoustic Core - Euro Class B

Norma | Lacquered Fire retardant HMDF (FR)
- Lacquered Fire Retardant HMDF
- Fire Retardant HMDF Structural Frame
- Sound PET Acoustic Core - Euro Class B

* finished with a white or black primer paint that gives it a raw, matte effect.



The panelling range is installed to battens that can be installed onto any type of surface. If you want to conceal the sides of the installation use Metal Side covers

_______

Range | Dimensions:
Norma 8 | Norma 10 | Norma 12 | Norma 16
- (FG) 800x1184x39mm
- (FR) 800x1184x40mm

Fixing Systems

Wall & Ceiling
+ Panelling Batten
Add-ons
+ Panelling - Metal Side Cover

Norma - Panelling | Range

Overview

Purpose

- RT reduction

- Improving speech intelligibility

- Extended mid-low frequency Absorption

- High frequency absorption

- Noise Reduction

Recommended for

- Offices

- Conference Rooms

- Meeting Rooms

- Schools

- Auditoriums





Absorption Range: 315 Hz to 3150 Hz

Acoustic Class: C | (aw) = 0,7



Perforated area: 5%



Carbon positive Natural Wood - Carefully selected wood from controlled, sustainable sources.

Recycled PET absorption - Class 1 product according to the OEKO-TEX@ Standard 100.
_______

This product is available in the following Fire Rates:
FG | Furniture Grade
FR | Fire Rated
_______

PRODUCT COMPOSITION:

Norma 8 | Natural Wood Veneer (FG)

- Natural Wood Veneer

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 8 | Primer Finished HMDF (FG)

- Primer Finished HMDF *

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 8 | Natural Wood Veener (FR)

- Natural Wood Veneer

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



Norma 8 | Lacquered Fire retardant HMDF (FR)

- Lacquered Fire Retardant HMDF

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



* finished with a white or black primer paint that gives it a raw, matte effect.



The panelling range is installed to battens that can be installed onto any type of surface. If you want to conceal the sides of the installation use Metal Side covers







Dimensions:

FG - PP | 800x1184x39mm

FG - LW | 800x1184x39mm

FG - NW | 800x1184x39mm

FR - LW | 800x1184x40mm

FR - NW | 800x1184x40mm

Fixing Systems

Wall & Ceiling

+ Panelling Batten

Add-ons

+ Panelling - Metal Side Cover

Available Finishes:

(FG - PP) Painted Primer Finishes (FG - LW) Lacquered Wood Finishes (FG - NW) Natural Wood Finishes (FR - LW) Lacquered Wood Finishes (FR - NW) Natural Wood Finishes

Interested in this product? Contact us

Purpose

- RT reduction
- Improving speech intelligibility

- Extended mid-low frequency Absorption

- High frequency absorption

- Noise Reduction

Recommended for

- Offices

- Conference Rooms

- Meeting Rooms

- Schools

- Auditoriums





Absorption Range: 315 Hz to 3150 Hz

Acoustic Class: C | (aw) = 0,7



Perforated area: 7%



Carbon positive Natural Wood - Carefully selected wood from controlled, sustainable sources.

Recycled PET absorption - Class 1 product according to the OEKO-TEX@ Standard 100.
_______

This product is available in the following Fire Rates:
FG | Furniture Grade
FR | Fire Rated
_______

PRODUCT COMPOSITION:

Norma 10 | Natural Wood Veneer (FG)

- Natural Wood Veneer

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 10 | Primer Finished HMDF (FG)

- Primer Finished HMDF *

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 10 | Natural Wood Veener (FR)

- Natural Wood Veneer

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



Norma 10 | Lacquered Fire retardant HMDF (FR)

- Lacquered Fire Retardant HMDF

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



* finished with a white or black primer paint that gives it a raw, matte effect.



The panelling range is installed to battens that can be installed onto any type of surface. If you want to conceal the sides of the installation use Metal Side covers





Dimensions:

FG - PP | 800x1184x39mm

FG - LW | 800x1184x39mm

FG - NW | 800x1184x39mm

FR - LW | 800x1184x40mm

FR - NW | 800x1184x40mm

Fixing Systems

Add-ons

+ Panelling - Metal Side Cover

Wall & Ceiling

+ Panelling Batten

Available Finishes:

(FG - PP) Painted Primer Finishes (FG - LW) Lacquered Wood Finishes (FG - NW) Natural Wood Finishes (FR - LW) Lacquered Wood Finishes (FR - NW) Natural Wood Finishes

Interested in this product? Contact us

Purpose

- RT reduction
- Improving speech intelligibility

- Extended mid-low frequency Absorption

- High frequency absorption

- Noise Reduction

Recommended for

- Offices

- Conference Rooms

- Meeting Rooms

- Schools

- Auditoriums





Absorption Range: 315 Hz to 3150 Hz

Acoustic Class: C | (aw) = 0,7



Perforated area: 11%



Carbon positive Natural Wood - Carefully selected wood from controlled, sustainable sources.

Recycled PET absorption - Class 1 product according to the OEKO-TEX@ Standard 100.
_______

This product is available in the following Fire Rates:
FG | Furniture Grade
FR | Fire Rated
_______

PRODUCT COMPOSITION:

Norma 12 | Natural Wood Veneer (FG)

- Natural Wood Veneer

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 12 | Primer Finished HMDF (FG)

- Primer Finished HMDF *

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 12 | Natural Wood Veener (FR)

- Natural Wood Veneer

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



Norma 12 | Lacquered Fire retardant HMDF (FR)

- Lacquered Fire Retardant HMDF

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B

* finished with a white or black primer paint that gives it a raw, matte effect.



The panelling range is installed to battens that can be installed onto any type of surface. If you want to conceal the sides of the installation use Metal Side covers







Dimensions:

FG - PP | 800x1184x39mm

FG - LW | 800x1184x39mm

FG - NW | 800x1184x39mm

FR - LW | 800x1184x40mm

FR - NW | 800x1184x40mm

Fixing Systems

Wall & Ceiling

+ Panelling Batten

Add-ons

+ Panelling - Metal Side Cover

Available Finishes:

(FG - PP) Painted Primer Finishes (FG - LW) Lacquered Wood Finishes (FG - NW) Natural Wood Finishes (FR - LW) Lacquered Wood Finishes (FR - NW) Natural Wood Finishes

Interested in this product? Contact us

Purpose

- RT reduction
- Improving speech intelligibility

- Extended mid-low frequency Absorption

- High frequency absorption

- Noise Reduction

Recommended for

- Offices

- Conference Rooms

- Meeting Rooms

- Schools

- Auditoriums





Absorption Range: 315 Hz to 3150 Hz

Acoustic Class: C | (aw) = 0,7



Perforated area: 19%



Carbon positive Natural Wood - Carefully selected wood from controlled, sustainable sources.

Recycled PET absorption - Class 1 product according to the OEKO-TEX@ Standard 100.
_______

This product is available in the following Fire Rates:
FG | Furniture Grade
FR | Fire Rated
_______

PRODUCT COMPOSITION:

Norma 16 | Natural Wood Veneer (FG)

- Natural Wood Veneer

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 16 | Primer Finished HMDF (FG)

- Primer Finished HMDF *

- Marine Grade Plywood Structural Frame

- Sound PET acoustic core - Euro Class B



Norma 16 | Natural Wood Veener (FR)

- Natural Wood Veneer

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



Norma 16 | Lacquered Fire retardant HMDF (FR)

- Lacquered Fire Retardant HMDF

- Fire Retardant HMDF Structural Frame

- Sound PET Acoustic Core - Euro Class B



* finished with a white or black primer paint that gives it a raw, matte effect.



The panelling range is installed to battens that can be installed onto any type of surface. If you want to conceal the sides of the installation use Metal Side covers







Dimensions:

FG - PP | 800x1184x35mm

FG - LW | 800x1184x35mm

FG - NW | 800x1184x35mm

FR - LW | 800x1184x40mm

FR - NW | 1184x800x40mm

Fixing Systems

Wall & Ceiling

+ Panelling Batten

Add-ons

+ Panelling - Metal Side Cover

Available Finishes:

(FG - PP) Painted Primer Finishes (FG - LW) Lacquered Wood Finishes (FG - NW) Natural Wood Finishes (FR - LW) Lacquered Wood Finishes (FR - NW) Natural Wood Finishes
